Polymer Timing Belt Conveyer Roller
1. Compact structure, tension free, simple design.
2.T5 tooth profile suitable for roller conveying, higher universality.
3. Accurate positioning, combine with MDR can match the application of transplant section.
4. Combine with PU Timing belt can match the application of clean room and other harsh environment.
5. Self-lubricating and maintenance-free.
6.Temperature range: - 5℃ ~ + 40℃
7.Applicable humidity: 30%~90%RH(non-condensation)
description:

1.The polymer timing pulley is installed at the end of the roller, which makes the drive

and conveying separate in the zone. The conveying is more stable and has the

characteristics of high speed and low noise.

2.The bearing end cap consists of a precision ball bearing, a polymer housing and

end cap seal. Combined they provide an attractive, smooth and quite running

roller.

3.The design of the end cap protects the bearings by providing excellent resistance

to dust and splashed water.

4.larger transmission capability, compact structure, tensioning-free mechanism and

simple design.

5.It is more efficient without slip in conveying.

6.The T5 tooth shape design is suitable for the roller conveyor with higher versatile.

7.Its positioning is precise with the use of MDR to meet the application requirements

of the load section.

8.It is suitable for clean room and other harsh environment with the use of PU

synchronous belt.

9.Compared with traditional belt drive, it is waterproof (no skidding) and has the

ability to work in a certain bad environment.

10.It needs no lubrication with easy maintenance.

11.Different timing belt models match the different center distance of the roller. (see

the appendix)

12.Suitable for the high speed applications. Maximum speed varies with roller length

and diameter. Maximum speed up to 2~3m/s.

13.Standard configuration with anti-static design surface impedance≤ Ω。

14.Temperature: -5℃~+40℃.

15.Humidity range: 30-90% RH (non-condensation).

     Please contact us if humidity out of this scope.



D

T

Shaft

Tube

Steel Z/P

SS

Aluminium

Φ50

1.5

Φ14/15


Remark: Φ50 rollers can be fitted with PVC sleeve (2mm) and PU sleeve (2mm).
